Rotary Dryer

Product Details:

Fuel Type Coal, Gas, Oil, Biomass
Temperature Up to 400C
Heat Source Direct or Indirect
Power Consumption Depends on model and capacity
Power 7.5 kW to 75 kW (depends on capacity)
Material Mild Steel / Stainless Steel
Technology Rotary Drum Technology
Share Your Product:

Get a Price/Quote

Request To Call Back Send Inquiry

Rotary Dryer Price And Quantity

Minimum Order Quantity 1 Unit

Rotary Dryer Product Specifications

Power 7.5 kW to 75 kW (depends on capacity)
Material Mild Steel / Stainless Steel
Power Consumption Depends on model and capacity
Temperature Up to 400C
Heat Source Direct or Indirect
Technology Rotary Drum Technology
Dimension (L*W*H) Customized as per requirement
Fuel Type Coal, Gas, Oil, Biomass

Rotary Dryer Trade Information

Supply Ability 10-20 Unit Per Day
Delivery Time 7- Week

Product Description

Encouraged by the considerable support of our professionals, we are able to manufacture, supply and export Rotary Dryer. These products are used in different industries like metallurgy, cement and chemical. Owing to their heavy duty drying process, these products help in drying chalk slags, coal powder, slags and clay. With better adaptability and perfect workmanship, these products are very popular among our clients. Rotary Dryer is delivered to the clients in a designated time frame owing to our expert delivery team.

Features of Rotary Vacuum Dryer:

Convenient operation
High yield
Less energy consumption
Varied fuel options

Dryer capacity material 950 - 1000 Sheets / Day

Chip Board-dryer out shell thickness 10mm
Inner side two shell thickness 8mm
Dryer rings thickness 60 to 65mm x 150mm width
Dryer frame channel size 75mm x 200mm
Couple with 04 rollers dryer wheel cast iron
Forged Dia 460mm x 175mm with bearing and brackets
Reinforcement rings with channels 21/2" x 5"
Dryer with Dynamic Balance with insulation
Dryer insulation with glass wool thickness 65 mm and conversing sheet thickness 26 gauge
Dryer coupled with variable Gear and motor (7.5KW) 6 to 7 R.P.M
Cyclone For Dry Material (Without Structure)
Dryer material collection cyclone
Dia 2000 mm x 2000 mm x 5mm
With inlet outlet and exhaust connectors
Heating Chamber (Without Bricks)
For hot gasses dia 2700 mm x 4880 mm x 6mm(Bottom side opened and top side closed)
Heating chamber to dryer pipelines
Dia 1000 mm x 6 mm
Total Length 1000 mm (Without Pipe)

Blower For Dryer

Pneumatic Blower: 387000 CuM/Hr
Blower Speed: 1000 RPM
Blower will be fitted with V-Belt drive fan structure will be fabricated with 10mm sheet thickness with accessories according to capacity(Without Motor 55 Kw)

Dust Feeding Blower

With Dust Burner
Dust Feeding Blower coupled with Motor 7.5 H.P Brackets and Bearings.

Technical Details:

Dryer Capacity	350 to 1000 sheets 8' x 4' per day
Wood Moisture	45%
Bagasse Moisture	50% to 54%
Required outlet Moisture	3% to 4%
Feed Rate (kg/s) Wet Material	1.02
Oven dry material(Kg/s)	0.770
Products Flow Rate
Dry Temperature Exit	90 - 100
Efficiency MJ/Kg Residential Time	20 to 30 Minutes

Advanced Drying Performance

Our rotary drum dryers deliver superior drying efficiency with customizable heat sources and capacities, accommodating diverse industrial needs. Built to operate at high temperatures and constructed with robust materials, these dryers provide consistent, controlled drying for various materials, maximizing throughput and minimizing operational downtime.

Flexible Power and Fuel Options

Choose from coal, gas, oil, or biomass as fuel options, allowing adaptability based on resource availability and operational preferences. Power requirements range from 7.5 kW to 75 kW, depending on capacity, ensuring you get the most energy-efficient solution tailored to your process demands.

FAQs of Rotary Dryer:

Q: How does the rotary drum dryer work?

A: The rotary drum dryer utilizes a cylindrical drum that rotates while material passes through it. Heated airgenerated by direct or indirect heat sources using coal, gas, oil, or biomassflows through the drum, efficiently evaporating moisture from the feed, resulting in uniformly dried output.

Q: What materials can be processed using this rotary dryer?

A: This dryer can effectively process a wide range of bulk materials, including agricultural products, minerals, chemicals, and biomass. The choice between mild steel or stainless steel construction allows compatibility with corrosive, abrasive, or specialty materials.

Q: When should I choose between direct and indirect heating options?

A: Direct heating is recommended when the material can be in contact with combustion gases, ensuring faster and more efficient drying. Indirect heating is preferable for sensitive or contaminated-prone materials requiring a barrier between the heat source and the feed.

Q: Where are these rotary dryers manufactured and supplied?

A: Our rotary dryers are manufactured in India and supplied across domestic and international markets through a reliable dealer, distributor, exporter, and wholesaler network.

Q: What is the process for customizing dryer dimensions and capacity?

A: To customize your rotary dryer, simply share your material type, required capacity, and available installation space. Our team will tailor the drum dimensions (length, width, and height) and suggest suitable power and fuel options for optimal performance.

Q: How does usage of different fuels impact dryer operation?

A: Selecting coal, gas, oil, or biomass as fuel influences operating costs and drying rates. Gas and oil generally provide easier temperature control, while coal and biomass may offer cost advantages in specific regions. Each fuel is supported by our robust burner systems.

Q: What benefits does this rotary dryer offer for industrial drying?

A: With high-temperature operation up to 400C and customizable design, our rotary dryer enhances drying efficiency, reduces energy consumption, and supports large-scale material processing, making it ideal for industrial applications seeking reliable, cost-effective drying solutions.
